The mta OEM soldering robot for integrator is designed for handling semi or fully automatic selective point-to-point soldering from above.
Thanks to its unique concept, it comes with a process guarantee and is delivered directly to the system manufacturer.
The robot is compatible with all mta soldering heads: iron, induction, microflame – except for the mta MLH45 laser head.
The 3 or 4 axes of the OEM robot are fully programmable through the mta-MotionEditor software, including soldering parameters such as:
– Solder quantity
– Wire feed speed
– Preheating/postheating times
– Automatic tip cleaning cycle intervals
– Other parameters for each soldered point
Furthermore, its flexible, modular design allows for seamless integration into automated production lines.
The main features of our OEM robot include:
- Welded frame construction
- 4-axis soldering robot, Y-axis in the base to also present parts to the operator
- 300x300mm or 500×500 working area
- Industrial PC controller with Embedded Windows® operating system
- Intuitive menu-driven mta MotionEditor software
4 reasons to choose the mta OEM soldering robot
- The X, Y, and Z axis use ball-screw actuators for precise actuation with a repeatability of ±20 μm to assure the process is accurate and delivers consistent quality.
- As properly designed heads are fairly heavy, the system uses large DC stepper motors to provide the necessary strength for fast actuation.
- The OEM platform offers a high flexibility in terms of mechanical and electrical integration i.e. it can be easily and securerly integrated into the customer’s machine.
- Intuitive menu-driven mta MotionEditor software.
